The Crosby 1018623 S-209 screw pin anchor shackle is a heavy-duty Grade 6 rigging component with a 17-ton working load limit. Its closed-die-forged, quenched-and-tempered carbon-steel body and alloy-steel screw pin provide the strength, ductility, and fatigue resistance required for demanding lifting and rigging applications.
Specifications
- Brand: Crosby
- Manufacturer part number: 1018623
- UPC: 662547186236
- Series: S-209
- Product type: Screw pin anchor shackle
- Nominal shackle size: 1-1/2 in.
- Working load limit: 17 tons
- Body material: Forged, quenched-and-tempered carbon steel
- Pin material: Alloy steel
- Finish: Self-colored red
- Pin diameter: 1.63 in.
- Throat opening: 2.38 in.
- Inside length: 5.75 in.
- Inside width: 3.88 in.
- Outside eye diameter: 3.63 in.
- Overall length: 10 in.
- Overall width: 7.33 in.
- Design factor: 6:1
- Temperature range: -40°F to 400°F
- Fatigue rating: 20,000 cycles at 1.5 times the working load limit
- Identification: Permanently marked working load limit and Grade 6 designation
- Inspection feature: Crosby QUIC-CHECK angle indicators
- Applicable standard: Meets or exceeds ASME B30.26 requirements
- Country of origin: USA
- Quantity: 1 shackle
