Crosby 1017582 G-209A Grade 8 Alloy Screw Pin Anchor Shackle, 1 in., 12.5 Ton WLL (Each)
CBY-1017582
- Low stock - 8 items left
- Backordered, shipping soon
The Crosby 1017582 G-209A is a Grade 8 alloy screw pin anchor shackle designed for heavy-duty lifting and rigging applications. Its forged, quenched-and-tempered alloy-steel construction delivers a 12.5-ton working load limit in a compact 1-inch body size. The hot-dip galvanized finish provides corrosion resistance, while the removable screw pin allows convenient rigging connections.
Specs:
Brand: Crosby
MPN: 1017582
Model: G-209A
Product Type: Alloy Screw Pin Anchor Shackle
Nominal Size: 1 in.
Working Load Limit: 12.5 Tons / 25,000 lb.
Grade: Grade 8
Design Factor: 4.5:1
Material: Forged, Quenched-and-Tempered Alloy Steel
Pin Material: Alloy Steel
Pin Type: Removable Screw Pin
Finish: Hot-Dip Galvanized
Width Between Eyes: 1.69 in.
Pin Diameter: 1.16 in.
Inside Length: 3.76 in.
Inside Bow Width: 2.69 in.
Overall Width: 4.69 in.
Overall Length: 6.56 in.
Operating Temperature Range: -40°F to 400°F
Product Weight: 5.32 lb.
Standard Compliance: Meets or Exceeds ASME B30.26
Federal Specification: RR-C-271H, Type IVA, Grade B, Class 2 Performance Requirements
Selling Unit: Each
