Profax PXAEC-4000-1-045CF Arc Gouging Torch with 7 ft Swivel Cable and Insulation Kit (Each)

The Profax PXAEC-4000-1-045CF is a complete air carbon-arc gouging torch assembly equipped with a 7-foot, 360-degree swivel cable and an installed power-and-air insulation kit. Its 15-degree head provides a comfortable working angle, while the forged copper-alloy body and heat-resistant construction support demanding metal removal applications.

The torch accepts carbon electrodes from 5/32 to 1/2 inch and operates at up to 1,000 amps, depending on electrode size. A field-serviceable air valve and swivel cable help improve maneuverability and simplify maintenance.

Specs

• Brand: Profax

• MPN: PXAEC-4000-1-045CF

• Manufacturer Model: AEC-4000-1-045CF

• Product Type: Air Carbon-Arc Gouging Torch Assembly

• Process: Air Carbon-Arc Cutting and Gouging

• Cable Length: 7 ft (2.1 m)

• Cable Configuration: 360° Swivel

• Torch-Head Angle: 15°

• Electrode Range: 5/32–1/2 in

• Maximum Output: 1,000A DC

• 5/32 in Electrode Range: 90–150A DC

• 3/16 in Electrode Range: 200–250A DC

• 1/4 in Electrode Range: 300–400A DC

• 5/16 in Electrode Range: 350–450A DC

• 3/8 in Electrode Range: 450–600A DC

• 1/2 in Electrode Range: 800–1,000A DC

• Recommended Compressed-Air Pressure: 80–100 PSI

• Body Material: Forged Copper Alloy

• Handle Material: High-Impact, Heat-Resistant Material

• Air-Valve Design: Field Serviceable

• Included Kit: AEC-3-045CF Power-and-Air Insulation Kit, Installed

• Recommended Applications: Gouging, Cutting, Grooving, Beveling, Scarfing, and Piercing Metal

• Country of Origin: USA

• Selling Unit: Each
